1. Measurement Range & Performance:
Measurement technology: Primary nephelometric scatter detection (90°)
Turbidity Range: 0 to 1000 NTU (Nephelometric Turbidity Units)
Resolution: Measures turbidity as low as 0.01 NTU (0 to 9.99 NTU), 0.1 NTU (10 to 99.9 NTU), 1 NTU (100 to 1000 NTU)
Accuracy: Reads within +-2% of the displayed value or 0.02 NTU, (whichever is greater), with additional consideration of stray light across the entire range.
Repeatability: Consistent readings of +-1% of displayed value or 0.01 NTU, (whichever is greater).
Stray Light: < 0.02 NTU
Temperature Compensation: Get accurate results with ambient Temperature & LED Self Heating compensation.
2. Optics:
Detection: Silicon Photodiode x 2 (90° scatter & 180° attenuated measurement)
Light Source:
For ISO7027: LED with wavelength of 860 nm (830 -890nm FWHM) for infrared light source
For EPA 180.1: White LED light source
Response Time: Quick response with <7 seconds for readings (in normal reading mode)
3. Power & Battery:
Power Supply: Rechargeable lithium-ion cell for long lifespan, fast charging, and low maintenance, making it ideal for portable applications.
Battery Life: 2500 sequential tests in one charge (full backlight & Wi-Fi Active) Battery Health: Retains 75% of original capacity after 500 charge cycles
Auto Off Feature: Save battery life after finishing tests with programmable auto off
Compliance: UL2054 & IEC62133
Charging Method: USB Type C charging port (4 hours from zero to full charge)
4. Calibration & Check Standards:
Calibration Options: Safe and non-hazardous solutions to ensure user health and safety. Three-point user calibration using SDVB calibration standards (20 NTU, 100 NTU, 400 NTU).
Check Standards: Verify the calibration of the instrument in the field. Serial number certificate provided for check standards traceability. Includes 1 NTU calibration to verify the accuracy at lower range.
5. Data Storage & Transfer:
Data Logging: 5,000 results in text log accessible via PC
Instrument Test Log: Access at least 1,000 recent tests with detailed data tags (users, labels, notes etc.) on the instrument directly.
Connectivity: USB-C and Wi-fi (for Data Transfer) and Bluetooth 5.1 (for Link to compatible Palintest Products)
USB Port: USB-C for direct data download to PC and charging
Cloud Storage: Palintest Connect enabled to upload & view data remotely, register warranty, view instrument certificate.
